LCR Meter UNI-T UT622A

The UT622 series offers high performance, handheld component measurement devices (LCR meter) that measure inductances, resistances and capacitors, as well as their secondary parameters D (dissipation factor), Q (quality factor), Θ (phase angle in degrees), Θ (phase angle in radians) and ESR (series or parallel equivalent resistance) can be measured.

Features

• Manual LCR meter for primary and secondary parameters of components.
• Automatic component identification
• measurement with AC voltage 100, 120, 1000 or 10000 Hz.
• large backlit TFT LCD display with 10 brightness levels
• the display range is maximum 99999 meters
• maximum accuracy 0.1
• possibility to select components according to given tolerances
• selectable amplitude measuring voltage 0.1 Vrms, 0.3 Vrms, 1.0 Vrms
• equivalent mode selection (for Z <100 Ω serial, for Z < 10k Ω parallel).
• Mini-USB interface for data transfer to PC / charging the device.
• built-in high capacity rechargeable battery: 1800 mAh
• Power supply: Rechargeable battery or AC adapter
• Running time with one battery charge: approx. 8 hours
• functions in recording mode and data statistics: AVG (average), MAX, MIN
• Automatic power off: yes after 5, 15, 30, 60 minutes
• Audible and visual alarm to compare tolerance results
• Reset open circuit or short circuit tester: yes
• Tolerance value setting from nominal value: 1 % to 20 %, default 5 %.
• Component counting: all, compliant, non-compliant

Package Included:

• 1 x
• 1 x
• 2 x
