Power Profiler

Current measurement tool for embedded development

Power Profiling made easy
The Power Profiler Kit II (PPK2) is an easy-to-use tool for current measurements and power consumption optimization of embedded solutions. The PPK2 connectors can be connected to any Nordic DK or custom board as a standalone unit, i.e. there are no requirements for additional kits or debuggers. The PPK2 supports both a source mode and an ampere meter mode. In the source mode, shown as source measure unit (SMU) on the PCB, the PPK2 both supplies power and measures the current of the external device under test (DUT). The source mode has an on-board regulator capable of supplying up to 1A peak currents. Both modes support VCC levels between 0.8V and 5V. In the ampere meter mode, the DUT is powered by a separate power source.

High accuracy and resolution
The PPK2 has an advanced analog measurement unit with a high dynamic input range. This allows for accurate current consumption measurements for the entire range typically seen in embedded applications, all the way from 200nA to 1A. This allows measuring everything from Power Off mode of the DUT to the maximum power consumption of any Nordic DUT or external HW with headroom to spare for additional circuit draw, e.g. an nRF9160 DK with external sensors.
The resolution varies between 100nA and 1mA, depending on the current measurement range. The time resolution is also high enough to detect spikes. This is achieved by having a 100 ksps sampling rate of the current, 10x the resolution of the long term view of our previous generation PPK. Improve code debugging The PPK2 includes support for 8 digital inputs that can be used as a low-end logic analyzer. This makes it possible to instrument the code and make it easy to link the power consumption to blocks of code being executed.

Key features
1. 200nA to 1A current measurement range with a resolution that varies between 100nA and 1mA.
2. Source mode and ampere meter mode
3. Source mode includes built-in programmable regulator with a 0.8V to 5V output range and up to 1A current supply

4. 100 ksps sampling rate (10 x greater than previous generation)
5. Standalone unit
6. 8 digital inputs for low-end logic analyzer support
7. Measure instantaneous and average current on all Nordic DKs, in addition to custom boards
8. Supported through nRF Connect for Desktop’s Power Profiler app

9. Export measurement data for post- processing.

Applications
1. Power debugging of embedded applications
2. Estimate battery lifetime of completed
solution

Kit content
1. Power Profiler Kit II board
2. 4-pin current measurement cable, 10-pin logic port cable

Needed resources
1. nRF Connect for Desktop’s Power Profiler app
